| Power loss |
6.6 |
| Rated voltage |
|
| Number of poles |
3 |
| Device construction |
Built-in device fixed built-in technique |
| Motor drive optional |
yes |
| Motor drive integrated |
no |
| Type of control element |
Toggle |
| Degree of protection (IP) |
IP20 |
| Rated permanent current Iu |
125 |
| With switched-off indicator |
no |
| Overload release current setting |
|
| Integrated earth fault protection |
no |
| Complete device with protection unit |
yes |
| With integrated under voltage release |
no |
| DIN rail (top hat rail) mounting optional |
no |
| Suitable for DIN rail (top hat rail) mounting |
no |
| Type of electrical connection of main circuit |
Bolt connection |
| Position of connection for main current circuit |
Front side |
| Adjustment range undelayed short-circuit release |
|
| Number of auxiliary contacts as change-over contact |
0 |
| Number of auxiliary contacts as normally open contact |
0 |
| Number of auxiliary contacts as normally closed contact |
0 |
| Adjustment range short-term delayed short-circuit release |
|
| Rated short-circuit breaking capacity Icu at 400 V, 50 Hz |
- |
