| Cable entry |
Other |
| Number of poles |
4 |
| Suitable for fuses |
14x51 mm |
| Motor drive optional |
no |
| With error protection |
- |
| Motor drive integrated |
no |
| Version as main switch |
yes |
| Type of control element |
Long turning handle |
| Equipped with connectors |
yes |
| Position control element |
- |
| Version as safety switch |
yes |
| Rated permanent current Iu |
32 |
| Suitable for floor mounting |
no |
| Suitable for front mounting |
no |
| Suitable for busbar mounting |
yes |
| Max. rated operation voltage Ue AC |
1000 |
| Degree of protection (IP), front side |
IP20 |
| Rated operation power at AC-23, 400 V |
22 |
| Rated short-time withstand current lcw |
1 |
| Version as emergency stop installation |
no |
| Conditioned rated short-circuit current Iq |
80 |
| Type of electrical connection of main circuit |
Screw connection |
