| Depth |
135 |
| Width |
200 |
| Height |
300 |
| Interlockable |
yes |
| Number of poles |
6 |
| Number of switches |
1 |
| Device construction |
Complete device in housing |
| Motor drive optional |
no |
| Colour control element |
Black |
| Motor drive integrated |
no |
| Version as main switch |
yes |
| Rated operating voltage |
|
| Type of control element |
Long turning handle |
| Switching power at 400 V |
37 |
| Version as safety switch |
no |
| Voltage release optional |
no |
| Rated permanent current Iu |
80 |
| With pre-assembled cabling |
- |
| Degree of protection (NEMA) |
Other |
| Suitable for floor mounting |
- |
| Version as reversing switch |
no |
| Max. rated operation voltage Ue AC |
750 |
| Suitable for front mounting 4-hole |
no |
| Suitable for front mounting centre |
no |
| Suitable for intermediate mounting |
- |
| Width in number of modular spacings |
- |
| Rated operation power at AC-3, 400 V |
- |
| Degree of protection (IP), front side |
IP65 |
| Rated operation power at AC-23, 400 V |
37 |
| Rated short-time withstand current lcw |
1 |
| Version as emergency stop installation |
no |
| Version as maintenance-/service switch |
yes |
| Rated permanent current at AC-21, 400 V |
80 |
| Rated permanent current at AC-23, 400 V |
75 |
| Conditioned rated short-circuit current Iq |
- |
| Suitable for distribution board installation |
yes |
| Type of electrical connection of main circuit |
- |
| Number of auxiliary contacts as change-over contact |
0 |
| Number of auxiliary contacts as normally open contact |
0 |
| Number of auxiliary contacts as normally closed contact |
0 |
