Categories
Features
|
Depth
|
82.5
|
|
Width
|
105
|
|
Height
|
160
|
|
Interlockable
|
yes
|
|
Number of poles
|
3
|
|
Number of switches
|
-
|
|
Device construction
|
Built-in device fixed built-in technique
|
|
Motor drive optional
|
yes
|
|
Colour control element
|
White
|
|
Motor drive integrated
|
no
|
|
Version as main switch
|
yes
|
|
Rated operating voltage
|
|
|
Type of control element
|
-
|
|
Switching power at 400 V
|
-
|
|
Version as safety switch
|
no
|
|
Voltage release optional
|
no
|
|
Rated permanent current Iu
|
250
|
|
With pre-assembled cabling
|
-
|
|
Degree of protection (NEMA)
|
-
|
|
Suitable for floor mounting
|
no
|
|
Version as reversing switch
|
no
|
|
Max. rated operation voltage Ue AC
|
690
|
|
Suitable for front mounting 4-hole
|
no
|
|
Suitable for front mounting centre
|
no
|
|
Suitable for intermediate mounting
|
no
|
|
Width in number of modular spacings
|
-
|
|
Rated operation power at AC-3, 400 V
|
-
|
|
Degree of protection (IP), front side
|
IP20
|
|
Rated operation power at AC-23, 400 V
|
-
|
|
Rated short-time withstand current lcw
|
3.6
|
|
Version as emergency stop installation
|
no
|
|
Version as maintenance-/service switch
|
no
|
|
Rated permanent current at AC-21, 400 V
|
250
|
|
Rated permanent current at AC-23, 400 V
|
-
|
|
Conditioned rated short-circuit current Iq
|
-
|
|
Suitable for distribution board installation
|
yes
|
|
Type of electrical connection of main circuit
|
Bolt connection
|
|
Number of auxiliary contacts as change-over contact
|
0
|
|
Number of auxiliary contacts as normally open contact
|
0
|
|
Number of auxiliary contacts as normally closed contact
|
0
|
