| Category type 2 |
yes |
| Max. PV-voltage |
- |
| Mounting method |
Other |
| Construction size |
3 modular spacing |
| Nominal voltage AC |
690 |
| Nominal voltage DC |
- |
| Leakage-current free |
no |
| Integrated backup fuse |
yes |
| System configuration DC |
no |
| System configuration IT |
yes |
| System configuration TN |
yes |
| System configuration TT |
no |
| Signalling at the device |
Optical |
| Voltage protection level |
- |
| Degree of protection (IP) |
IP20 |
| System configuration TN-C |
yes |
| System configuration TN-S |
no |
| Max. continuous voltage AC |
440 |
| Max. continuous voltage DC |
- |
| System configuration other |
no |
| System configuration TN-C-S |
no |
| Voltage protection level L-N |
- |
| Voltage protection level N-PE |
- |
| With remote signalling contact |
yes |
| Integrated short-circuit protection |
no |
| Max. discharge surge current (8/20) |
40 |
| Nominal discharge surge current (8/20) |
- |
| Number of conductors (without earthing) |
3 |
| Short-circuit breaking capacity (Isccr) |
50 |
| Max. conductor cross section flexible (fine-strand) |
16 |
| Max. conductor cross section solid (solid, stranded) |
25 |
| Integrated short-circuit protection selective to fuse gG |
50 |
| Max. overcurrent protection device, series connection (fuse) |
50 |
| Max. overcurrent protection device, parallel connection (fuse) |
- |
