Snap Lid Junction Box IP65 Grey 2.5mm

ABB

Snap Lid Junction Box IP65 Grey 2.5mm

Product identifiers

SKU: 2TKA140010G1

Categories

Wiring Accessories Waterproof Junction Boxes Junction Boxes Wiring Accessories & Installation

Specifications

Depth	38.000
Model	Junction box
Shape	Square
Width	75
Colour	White
Length	75
Castable	no
Diameter	-
Material	Plastic
Sealable	yes
Connectable	no
Cover model	Blind cover
Halogen free	yes
Weatherproof	yes
Equipped with	None
With screening	no
For Ex-zone gas	-
Mounting method	Universal
Cover attachment	Snapped on
For Ex-zone dust	-
Number of inlets	13
Circuit integrity	-
For tube diameter	-
Transparent cover	no
Surface protection	Untreated
Inlet from the rear	yes
Mounting in the soil	no
Mounting under water	no
Operating temperature
Explosion-tested version	no
Casting compound included	no
Degree of protection (IP)	IP65
Degree of protection (NEMA)	-
Rated insulation voltage Ui	400
Max. conductor cross section	18
Type of housing feed-through	Seal membrane
