| Width sensor |
46 |
| Coating housing |
Powder coating |
| Height of sensor |
176 |
| Housing material |
Metal |
| Length of sensor |
120 |
| Type of interface |
Other |
| Guard locking force |
3000 |
| With escape release |
yes |
| Type of guard locking |
- |
| With auxiliary release |
yes |
| With status indication |
yes |
| Construction type housing |
Special construction |
| Degree of protection (IP) |
IP67 |
| Type of switching contact |
Other |
| Degree of protection (NEMA) |
1 |
| Type of electric connection |
Other |
| Suitable for safety functions |
yes |
| Explosion safety category for gas |
- |
| Explosion safety category for dust |
- |
| Number of safety auxiliary contacts |
- |
| Ambient temperature during operating |
|
| Number of contacts as change-over contact |
- |
| Rated operation current Ie at AC-15, 24 V |
3 |
| Rated operation current Ie at DC-13, 24 V |
0.2 |
| Rated operation current Ie at AC-15, 125 V |
3 |
| Rated operation current Ie at AC-15, 230 V |
3 |
| Rated operation current Ie at DC-13, 125 V |
- |
| Rated operation current Ie at DC-13, 230 V |
- |
| Type of interface for safety communication |
Other |
| Number of contacts as normally open contact |
4 |
| Rated control supply voltage magnet drive DC |
|
| Number of contacts as normally closed contact |
2 |
| Rated control supply voltage magnet drive AC 50 Hz |
|
| Rated control supply voltage magnet drive AC 60 Hz |
|
