Categories
Features
|
Frequency
|
|
|
Power loss
|
6.3
|
|
Voltage type
|
AC/DC
|
|
Rated current
|
10
|
|
Rated voltage
|
400
|
|
Built-in depth
|
69
|
|
Explosion-proof
|
no
|
|
Pollution degree
|
3
|
|
Over voltage category
|
3
|
|
Current limiting class
|
3
|
|
Release characteristic
|
C
|
|
Number of poles (total)
|
3
|
|
Degree of protection (IP)
|
IP20
|
|
Number of protected poles
|
3
|
|
Flush-mounted installation
|
no
|
|
Rated insulation voltage Ui
|
440
|
|
Additional equipment possible
|
yes
|
|
Width in number of modular spacings
|
3.0
|
|
Ambient temperature during operating
|
|
|
Rated impulse withstand voltage Uimp
|
4
|
|
Concurrently switching neutral conductor
|
no
|
|
Connectable conductor cross section solid-core
|
|
|
Connectable conductor cross section multi-wired
|
|
|
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
|
10
|
|
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
|
-
|
|
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
|
25
|
|
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
|
15
|
