| Depth |
120 |
| Model |
Other |
| Width |
22.5 |
| Height |
84 |
| Release-delay |
|
| With start input |
yes |
| Control voltage 1 |
|
| Control voltage 2 |
|
| Evaluation inputs |
1-channel |
| Power consumption |
- |
| Supply voltage DC |
|
| Operating voltage DC |
|
| Rated switch current |
- |
| With muting function |
no |
| With feedback circuit |
yes |
| With detachable clamps |
yes |
| Supply voltage AC 50 Hz |
|
| Supply voltage AC 60 Hz |
|
| With approval for BG BIA |
no |
| Type of control voltage 1 |
DC |
| Type of control voltage 2 |
DC |
| Operating voltage AC 50 Hz |
|
| Operating voltage AC 60 Hz |
|
| SIL according to IEC 61508 |
3 |
| Suitable for rail mounting |
yes |
| Type of electric connection |
Screw connection |
| Voltage type (supply voltage) |
DC |
| With approval according to UL |
no |
| Voltage type (operating voltage) |
DC |
| Suitable for monitoring of valves |
yes |
| Stop category according to IEC 60204 |
0 |
| Type of safety according to IEC 61496-1 |
4 |
| Suitable for monitoring of tactile sensors |
no |
| Suitable for monitoring of magnetic switches |
yes |
| Suitable for monitoring of position switches |
yes |
| Performance level according to EN ISO 13849-1 |
Level e |
| Suitable for monitoring of proximity switches |
yes |
| Suitable for monitoring of emergency-stop circuits |
yes |
| Number of outputs, safety related, delayed, with contact |
0 |
| Number of outputs, safety related, delayed, semiconductors |
0 |
| Number of outputs, safety related, undelayed, with contact |
2 |
| Number of outputs, safety related, undelayed, semiconductors |
0 |
| Number of outputs, signalling function, delayed, with contact |
0 |
| Suitable for monitoring of optoelectronic protection equipment |
yes |
| Number of outputs, signalling function, delayed, semiconductors |
0 |
| Number of outputs, signalling function, undelayed, with contact |
0 |
| Number of outputs, signalling function, undelayed, semiconductors |
0 |
