| Category type 2 |
yes |
| Max. PV-voltage |
- |
| Mounting method |
DIN rail (top hat rail) 35 mm |
| Construction size |
1 modular spacing |
| Nominal voltage AC |
220 |
| Nominal voltage DC |
- |
| Leakage-current free |
- |
| Integrated backup fuse |
yes |
| System configuration DC |
no |
| System configuration IT |
no |
| System configuration TN |
yes |
| System configuration TT |
no |
| Signalling at the device |
Optical |
| Voltage protection level |
1.5 |
| Degree of protection (IP) |
IP20 |
| System configuration TN-C |
no |
| System configuration TN-S |
yes |
| Max. continuous voltage AC |
275 |
| Max. continuous voltage DC |
- |
| System configuration other |
no |
| System configuration TN-C-S |
yes |
| Voltage protection level L-N |
1.5 |
| Voltage protection level N-PE |
- |
| With remote signalling contact |
yes |
| Integrated short-circuit protection |
- |
| Max. discharge surge current (8/20) |
40 |
| Nominal discharge surge current (8/20) |
20 |
| Number of conductors (without earthing) |
2 |
| Short-circuit breaking capacity (Isccr) |
25 |
| Max. conductor cross section flexible (fine-strand) |
25 |
| Max. conductor cross section solid (solid, stranded) |
35 |
| Integrated short-circuit protection selective to fuse gG |
- |
| Max. overcurrent protection device, series connection (fuse) |
- |
| Max. overcurrent protection device, parallel connection (fuse) |
- |
