| Frequency |
|
| Power loss |
1.9 |
| Voltage type |
AC |
| Rated current |
10 |
| Rated voltage |
230 |
| Built-in depth |
69 |
| Explosion-proof |
no |
| Pollution degree |
2 |
| Over voltage category |
3 |
| Current limiting class |
3 |
| Release characteristic |
D |
| Number of poles (total) |
2 |
| Degree of protection (IP) |
IP20 |
| Number of protected poles |
1 |
| Flush-mounted installation |
no |
| Rated insulation voltage Ui |
500 |
| Additional equipment possible |
yes |
| Width in number of modular spacings |
1 |
| Ambient temperature during operating |
|
| Rated impulse withstand voltage Uimp |
4 |
| Concurrently switching neutral conductor |
yes |
| Connectable conductor cross section solid-core |
|
| Connectable conductor cross section multi-wired |
|
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V |
6 |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V |
- |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V |
10 |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V |
- |
