| Test class |
- |
| Max. PV-voltage |
- |
| Mounting method |
- |
| Number of poles |
1 |
| Construction size |
1 modular spacing |
| Remote signalling |
no |
| Nominal voltage AC |
- |
| Nominal voltage DC |
- |
| Specific energy (W/R) |
- |
| Integrated backup fuse |
no |
| System configuration DC |
no |
| System configuration IT |
no |
| System configuration TN |
yes |
| System configuration TT |
yes |
| Signalling at the device |
- |
| Voltage protection level |
- |
| Degree of protection (IP) |
IP20 |
| System configuration TN-C |
yes |
| System configuration TN-S |
yes |
| Max. continuous voltage AC |
- |
| Max. continuous voltage DC |
- |
| System configuration other |
no |
| System configuration TN-C-S |
no |
| Voltage protection level L-N |
- |
| Voltage protection level L-PE |
- |
| Voltage protection level N-PE |
1.5 |
| Voltage protection level (DC+ - DC-) |
- |
| Overcurrent protected voltage tapping |
no |
| Lightning impulse current (10/350 µs) |
25 |
| Voltage switching spark gap technology |
yes |
| Follow current extinguishing capability |
- |
| Voltage protection level (DC+/DC- - PE) |
- |
| Max. conductor cross section flexible (fine-strand) |
- |
| Max. conductor cross section solid (solid, stranded) |
- |
| Max. overcurrent protection device, series connection (fuse) |
- |
| Max. overcurrent protection device, parallel connection (fuse) |
- |
| Energy-coordinated protection effect with regard to the terminal equipment |
no |
