| Voltage type |
DC |
| Width sensor |
88 |
| Coating housing |
Uncoated |
| Diameter sensor |
- |
| Height of sensor |
50 |
| Housing material |
Stainless steel |
| Length of sensor |
14 |
| Type of actuation |
Magnet |
| Switching distance |
5 |
| Ambient temperature |
|
| Min. output current |
10 |
| With status indication |
yes |
| Rated supply voltage DC |
|
| Type of switching output |
PNP |
| Construction type housing |
Special construction |
| Degree of protection (IP) |
IP67 |
| SIL according to IEC 61508 |
3 |
| Degree of protection (NEMA) |
- |
| Type of electric connection |
Connector M12 |
| Protected switch distance ON |
8 |
| Protected switch distance OFF |
20 |
| Rated supply voltage AC 50 Hz |
|
| Rated supply voltage AC 60 Hz |
|
| Suitable for safety functions |
yes |
| Explosion safety category for gas |
None |
| Explosion safety category for dust |
None |
| Max. output current at protected output |
0.2 |
| Mechanical mounting condition for sensor |
Not flat |
| Number of protected semiconductor outputs |
3 |
| Type of interface for safety communication |
Other |
| Cross-/short circuit identification possible |
yes |
| Number of protected contact energized outputs |
- |
| Performance level according to EN ISO 13849-1 |
Level e |
| With monitoring function downstream switching devices |
no |
| Number of semiconductor outputs with signalling function |
- |
| Number of contact energized outputs with signalling function |
- |
