| Depth |
35 |
| Width |
35 |
| Height |
54.4 |
| Nominal current |
10 |
| Material contact |
Silver nickel (AgNi) |
| Drive, polarization |
Polarized |
| With LED indication |
no |
| Complete with socket |
no |
| Operating voltage DC |
|
| Max. starting current |
- |
| Type of switch contact |
Single contact |
| With detachable clamps |
no |
| Degree of protection (IP) |
IP40 |
| Drive, switching attitude |
Mono stable |
| Material of contact insert |
- |
| Operating voltage AC 50 Hz |
|
| Operating voltage AC 60 Hz |
|
| Voltage type for actuating |
AC |
| Material of contact surface |
Other |
| Type of electric connection |
Other |
| With forced-guided contacts |
no |
| Rated control supply voltage DC |
|
| Voltage type (operating voltage) |
AC/DC |
| Rated control supply voltage AC 50 Hz |
|
| Rated control supply voltage AC 60 Hz |
|
| Number of contacts as change-over contact |
3 |
| Number of contacts as normally open contact |
0 |
| Number of contacts as normally closed contact |
0 |
| Relay technology category according to IEC 61810-7 |
RT I |
