| Width sensor |
58 |
| Forced opening |
yes |
| Coating housing |
Other |
| Height of sensor |
103.5 |
| Housing material |
Metal |
| Length of sensor |
37.5 |
| Type of interface |
Other |
| With status indication |
no |
| Construction type housing |
Special construction |
| Degree of protection (IP) |
IP67 |
| Type of switching contact |
Other |
| Degree of protection (NEMA) |
1 |
| Type of electric connection |
- |
| Suitable for safety functions |
yes |
| Explosion safety category for gas |
None |
| Explosion safety category for dust |
None |
| Number of safety auxiliary contacts |
0 |
| Ambient temperature during operating |
|
| Number of contacts as change-over contact |
0 |
| Rated operation current Ie at AC-15, 24 V |
3 |
| Rated operation current Ie at DC-13, 24 V |
0.2 |
| Rated operation current Ie at AC-15, 125 V |
3 |
| Rated operation current Ie at AC-15, 230 V |
3 |
| Rated operation current Ie at DC-13, 125 V |
0.2 |
| Rated operation current Ie at DC-13, 230 V |
0.2 |
| Type of interface for safety communication |
Other |
| Number of contacts as normally open contact |
1 |
| Number of contacts as normally closed contact |
2 |
