NFZ40E-20 12-20VDC Contactor Relay

Name: NFZ40E-20 12-20VDC Contactor Relay
Brand: ABB
SKU: 1SBH136001R2040

NFZ 4 pole contactor relays - AC/DC operated, low consumption
* Part number: NFZ40E-20
* NF contactor relays are used for switching auxiliary and control circuits.
* These contactor relays are of the block type design with:
* 4 poles. Contactor relays have mechanically linked auxiliary contact elements (side-marked symbol)
* Control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage range (e.g. 100...250 V AC and DC)
- can manage large control voltage variations
- only 4 control voltage ranges covering 24...500 V 50/60 Hz and 20...500 V DC
- reduced panel energy consumption
- very distinct closing and opening.
- allow direct control by PLC-output = 24 V DC 500 mA
- can withstand short voltage dips and voltage sags
* Built-in surge suppression
* Add-on auxiliary contact blocks for front or side mounting and a wide range of accessories

Product identifiers

SKU: 1SBH136001R2040

Specifications

Depth	77
Width	45
Height	86
Interface	no
Mounting method	DIN-rail/screw
With LED indication	no
Operating voltage DC
Rated switch current	4
Rated operation current	3
Operating voltage AC 50 Hz
Operating voltage AC 60 Hz
Voltage type for actuating	DC
Suitable for manual operation	no
Rated control supply voltage DC
Voltage type (operating voltage)	-
Connection type auxiliary circuit	Screw connection
Rated operation current Ie, 400 V	3
Rated control supply voltage AC 50 Hz
Rated control supply voltage AC 60 Hz
Number of auxiliary contacts as change-over contact	0
Number of auxiliary contacts as normally open contact	4
Number of auxiliary contacts as normally closed contact	0
Number of auxiliary contacts as normally open contact, leading	0
Number of auxiliary contacts as normally closed contact, delayed switching	0
