| Depth |
46.5 |
| Width |
52.5 |
| Height |
57.5 |
| Interface |
no |
| Mounting method |
DIN rail |
| With LED indication |
no |
| Operating voltage DC |
|
| Rated switch current |
4 |
| Rated operation current |
4 |
| Operating voltage AC 50 Hz |
|
| Operating voltage AC 60 Hz |
|
| Voltage type for actuating |
DC |
| Suitable for manual operation |
no |
| Rated control supply voltage DC |
|
| Voltage type (operating voltage) |
DC |
| Connection type auxiliary circuit |
Screw connection |
| Rated operation current Ie, 400 V |
3 |
| Rated control supply voltage AC 50 Hz |
|
| Rated control supply voltage AC 60 Hz |
|
| Number of auxiliary contacts as change-over contact |
0 |
| Number of auxiliary contacts as normally open contact |
2 |
| Number of auxiliary contacts as normally closed contact |
2 |
| Number of auxiliary contacts as normally open contact, leading |
0 |
| Number of auxiliary contacts as normally closed contact, delayed switching |
0 |
